Schlage Latitude F10 Collins

<< Previous in Levers - Residential F-Series Next in Levers - Residential F-Series >>
Black
BlackSatin NickelBright Chrome 625Aged Bronze
Price: Log-in for Pricing

Product Options

Finish:
Schlage F10 Latitude with Collins Rose

Passage  Lever




Passage for Hallways and Closets





Click HERE to view hardware finishes



Features:
  • Interior Screws are Exposed
  • Adjusts to fit all standard door preparations
  • Lifetime finish and mechanical guarantee
  • Reversible lever allows for use as both right-hand and left-hand levers
  • Faceplates (Part 16-080): Supplied with 1/4" Round Corner and Drive-In Faceplates
  • Strike Plates (Part 10-027): Supplied with a Round Strike with Dimensions of 2-1/4" x 1-5/8"

Specifications:

  • Backset: 2-3/4" or 2-3/8", Adjustable
  • Handing: Reversible
  • Cross Bore: 2-1/8"
  • Edge Bore: 1"
  • Non-Locking
  • Door Thickness: minimum 1-1/2", maximum 1-3/4"
  • Lever Length: 4-1/8", Projection: 2-1/4"

F-Series Installation Instructions: Click HERE

(ANSI F75)
